ESW84 400W Peak (200W RMS) E-Series 8" Single 4-Ohm Subwoofer

Product Details:

• 8" Single 4-ohm E-Series Subwoofer
• Power Handling:
  • Peak: 400 watts
  • RMS: 200 watts
• 10mm mm Xmax
• Enhanced Pressed Paper Cone
• High-Roll Foam Surround
• Stamped Steel Vented Basket with NVX Punched Logo
• 1.5" High Temperature Copper Voice coil with Aluminum Former
• Progressive Roll Single-layer Spider with Integrated Tinsel Leads
• Optimized High-Velocity Pole Vent
• 46 oz. Single Stacked Ferrite Magnet with Protective Rubber boot
• Frequency Response: 20 - 200 Hz
• Resonance Frequency (Fs): 46.32 Hz
• Sensitivity: 83 dB
• Recommended sealed box volume: 0.5 cubic feet
• Recommended ported box volume: 0.75 cubic feet
• Top-mount depth: 4.19"
• Cutout diameter: 7.00"
• CTA-2031 Compliant
• 1-year Warranty from the Original Purchase Date
